   Air-Hydraulic Pumps     1800cc Reservoir Capacity

Use Maximum Pressure:700bar Use Reservoir Capacity : 1800cc

Use Reservoir Capacity : 1800cc

  • Reservoir Capacity : 1800cc

  • Output Flow Rate : 0.9 l/min

  • Maximum Pressure:700bar

  • For use of both Menual Valve : Use Double-Acting Cylinder

  • Plastic Case

  • Remort Control Switch

  • Air-Hydraulic Pumps

    • Specfication

    Model Output
    Pressure
    (Bar )         		Max.
    Air
    Pressure
    (Bar )    		 Tank
    Capacity
    (liter)    		 Required
    Oil
    (liter)     		Output
    Flow
    Rate
    (l/min)     		Weight
    (kgs)
    SDBA-700 700 6 2.5 1.8 0.9 7

    Custom made for special requirements
